Chiny Kołowrót Speed ​​Gate producent

Wymieniony producent kołowrotów dla pieszych i urządzeń parkingowych od ponad 15 lat!

Kod magazynowy: 832966

Polish
Poprosić o wycenę
Produkty

High Speed Swing Turnstile Gate with RFID QR Code Access Control

High Speed Swing Turnstile Gate with RFID QR Code Access Control
High Speed Swing Turnstile Gate with RFID QR Code Access Control
High Speed Swing Turnstile Gate with RFID QR Code Access Control High Speed Swing Turnstile Gate with RFID QR Code Access Control High Speed Swing Turnstile Gate with RFID QR Code Access Control High Speed Swing Turnstile Gate with RFID QR Code Access Control High Speed Swing Turnstile Gate with RFID QR Code Access Control High Speed Swing Turnstile Gate with RFID QR Code Access Control High Speed Swing Turnstile Gate with RFID QR Code Access Control High Speed Swing Turnstile Gate with RFID QR Code Access Control High Speed Swing Turnstile Gate with RFID QR Code Access Control High Speed Swing Turnstile Gate with RFID QR Code Access Control High Speed Swing Turnstile Gate with RFID QR Code Access Control High Speed Swing Turnstile Gate with RFID QR Code Access Control High Speed Swing Turnstile Gate with RFID QR Code Access Control High Speed Swing Turnstile Gate with RFID QR Code Access Control High Speed Swing Turnstile Gate with RFID QR Code Access Control High Speed Swing Turnstile Gate with RFID QR Code Access Control
Podstawowe informacje
Place of Origin: China
Nazwa handlowa: DOOR or OEM
Orzecznictwo: CE / IS09001
Model Number: DR.TD6629A-Black
Minimum Order Quantity: 1 lane
Cena: US $3000-US $3700
Packaging Details: Plywood box ，L1600×W140×H1000mm
Delivery Time: 2-8 weeks
Payment Terms: T/T
Supply Ability: 2500 sets per month
Najlepsza cena Skontaktuj się teraz
Material: SUS304 Stainless Steel + Aluminum Alloy Working environment: -25℃-+70℃
Pass speed: 35-40 personal/min Motor: Servo motor
Photocell: 12 pairs Passage Width: Standard 600mm, max 900mm
Swing arm available: Acrylic IP Rating: IP42
Mean Cycles Between Failure: 20 million times Voltage: AC110V/AC220V±10% 50-60Hz
Operating Power: Single Core 100w, dual core 200w Method of position: Motor + clutch + encoder
Podkreślić:

high speed swing turnstile gate

,

RFID QR code access control turnstile

,

speed gate turnstile with warranty

Swing Turnstile RFID/QR Code Bar Code High Speed Turnstile Gate Access Control
Product Specifications
Attribute Value
Material SUS304 Stainless Steel + Aluminum Alloy
Working environment -25℃ to +70℃
Pass speed 35-40 persons/min
Motor Servo motor
Photocell 12 pairs
Passage Width Standard 600mm, max 900mm
Swing arm available Acrylic
IP Rating IP42
Mean Cycles Between Failure 20 million times
Voltage AC110V/AC220V±10% 50-60Hz
Operating Power Single Core 100w, dual core 200w
Method of position Motor + clutch + encoder
Customization Options
  • Customized logo (Min. order: 2 pieces)
  • Customized packaging (Min. order: 2 pieces)
  • Graphic customization (Min. order: 2 pieces)
Supplier's Customization Ability
  • Minor customization
  • Drawing-based customization
  • Sample-based customization
  • Full customization
Shipping Information

Shipping fee and delivery date to be negotiated. Contact supplier for details.

High-End Screwless Fast Speed Turnstile Gate With 0.3S Servo Motor

This pedestrian speed gate turnstile features:

  • Top cover made of aluminum alloy with body constructed from brushed SUS304 stainless steel (2.0mm thickness) in elegant champagne gold finish
  • Anodized aluminum alloy surface after sandblasting for bright, delicate and smooth appearance
  • Traditional mortise and tenon process design with no visible screws or keyholes
  • Innovative hidden infrared design between double tempered glass
  • Precision gap of less than 0.2mm between components demonstrating superior craftsmanship
  • Servo motor with self-developed FOC control technology for precise positioning and silent operation
  • Ultra-fast opening time of 0.3 seconds
Advanced Safety Functions
  • Anti-trailing: Multiple infrared beam monitoring ensures one-person-one-card passage with alarm for unauthorized access
  • Anti-reverse: Precise infrared monitoring automatically blocks reverse passage with voice alarm
  • Triple safety protection:
    • Infrared anti-clip and anti-collision
    • Passing process logic anti-pinch
    • Current detection anti-clamp system
Optional Models
High Speed Swing Turnstile Gate with RFID QR Code Access Control 0 High Speed Swing Turnstile Gate with RFID QR Code Access Control 1 High Speed Swing Turnstile Gate with RFID QR Code Access Control 2
Applications

Ideal for:

  • Office and administrative buildings
  • Government and public buildings
  • Banks and financial institutions
  • Industrial installations
  • Residential areas
  • Schools, colleges and universities
Packing Details
  • Size: 169*34*118mm
  • Gross Weight:
    • Side cabinet: 125kg
    • Middle cabinet: 135kg
